Cast Iron Ball Valve

Description

The Cast Iron Ball Valve is a robust and reliable industrial valve designed to control the flow of liquids or gases in various applications. With its sturdy construction and exceptional performance, it is an ideal choice for demanding environments where durability and longevity are essential.The valve features a cast iron body, which provides excellent strength and corrosion resistance, making it suitable for use in diverse industries such as oil and gas, water treatment, chemical processing, and more. The cast iron construction ensures the valve can withstand high pressures and temperatures, making it highly versatile and adaptable to different operating conditions.



Drawing

Part	Material
Body	Cast Iron
Stem	Stainless Steel
Ball	Stainless Steel
Gland Packing	PEFE
Ball Beat	PEFE
Handle	FCD400



Technical Parameters

DN	15	20	25	32	40	50	65	80	100	125	150	200
	½"	¾"	1"	1¼"	1½"	2"	2½"	3"	4"	5"	6"	8"
L	108	117	127	140	165	178	190	203	229	356	394	457
H	59	63	75	86	97	131	142	170	201	252	286	340
D	89	98	108	117	127	152	178	191	229	254	279	343

Product Advantages

Robust Construction: CIBV are built with a sturdy body, providing exceptional strength and durability. This ensures reliable performance and longevity in demanding industrial environments.



Precise Flow Control: These valves feature a precision-engineered ball that enables precise flow control. When the valve is in the open position, the ball allows for unobstructed flow, while in the closed position, it rotates to block the flow tightly, ensuring accurate shut-off and preventing leakage.



Easy Operation: They are easy operation. They are equipped with levers or gear mechanisms that provide the necessary leverage to open or close the valve effortlessly, allowing for smooth and efficient flow control.



Versatile End Connections: CI Ball valves offer versatile end connections such as flanged ends or threaded connections, making them compatible with different piping systems.



FAQ

Q: Are CIBV suitable for high-pressure applications?
A: Yes, These Valves are designed to withstand high pressures and temperatures, making them suitable for use in demanding environments.



Q: How do I operate it?
A: It's typically operated by using a lever or gear mechanism. Simply rotate the lever or gear to open or close the valve,allowing for precise flow control.



Q: How does it compare to other valves
A: It offer advantages such as better flow control, reduced pressure drop, and improved sealing capabilities.
