Hydraulic Pressure Reducing Valve

Description

Pressure Reducing Valve automatically reduces a higher inlet pressure to a steady lower downstream pressure, regardless of changing flow rate and/or varying inlet pressure. The valve is an accurate, pilot-operated regulator capable of holding downstream pressure to a re-determined limit. When downstream pressure exceeds the pressure setting of the control pilot, the main valve and pilot valve close drip-tight.It's easy to install,repair,maintain and inspect.It has a long lasting working life.



Drawing

Part Name	Material
Body	Ductile Iron
Bonnet	Ductile Iron
Stem	2Cr13
Pressure Reducing Valve	Brass/Stainless Steel 304
Needle Valve	Brass/Stainless Steel 304
Ball Valve	Brass/Stainless Steel 304



Technical Parameters

Size	DN	L	Φ	Φ1	Φ2	N×Φ3
2''	50	203	99	125	165	4×Φ19
2-1/2''	65	216	118	145	185	4×Φ19
3''	80	241	132	160	200	8×Φ19
4''	100	292	156	180	220	8×Φ19
5''	125	330	184	210	250	8×Φ19
6''	150	356	211	240	285	8×Φ23
8''	200	458	266	295	340	12×Φ23
10''	250	530	319	355	405	12×Φ28



Features

Size:2''~10''

Nominal pressure: 1.6Mpa

Seal Test(Water): 1.8Mpa

Shell Test(Water): 2.4Mpa

Suitable temperature:0℃~80℃

Shell test :2.4 mpa

Suitable medium:water



Application Area

Urban water supply and industrial,agricultural water transmission lines,etc.
