Screw Down Check Globe Valve
Working Pressure: Options include PN16, PN25, PN40
Suitable Medium:Water,Oil,Gas
Description
The Screw Down Check Globe Valve is a cornerstone of industrial fluid control systems, renowned for its robust performance and unwavering reliability. Precision-engineered to ensure efficient operation and exceptional sealing capabilities, this valve is essential for maintaining peak performance across a wide spectrum of applications in various industries.
Technical Parameters
1.Drawing
2.COMPONENT
| NO. | Parts Name | Material |
| 1 | Body | BC6 |
| 2 | Bonnet | BC6 |
| 3 | Disc | BC6 |
| 4 | Stem | C377IBD OR BE |
| 5 | Gasket | NON-ASBESTOS |
| 6 | Handwheel | FC200 |
3.DIMENSIONS
| DN | d | L | D | C | NO. | h | t | H | D2 |
| 15 | 15 | 100 | 80 | 60 | 4 | 12 | 9 | 130 | 80 |
| 20 | 20 | 110 | 85 | 65 | 4 | 12 | 10 | 140 | 100 |
| 25 | 25 | 120 | 95 | 75 | 4 | 12 | 10 | 155 | 125 |
| 32 | 32 | 140 | 115 | 90 | 4 | 15 | 12 | 165 | 125 |
| 40 | 40 | 160 | 120 | 95 | 4 | 15 | 12 | 185 | 140 |
| 50 | 50 | 210 | 130 | 105 | 4 | 15 | 14 | 229 | 140 |
| 65 | 65 | 250 | 155 | 130 | 4 | 15 | 14 | 250 | 160 |
| 80 | 80 | 280 | 180 | 145 | 4 | 19 | 16 | 270 | 160 |
Product advantage
Efficient Check Mechanism: The Screw Down Check Globe Valve is equipped with a robust check mechanism designed to ensure unidirectional fluid flow, effectively preventing backflow and minimizing pressure loss within industrial fluid control systems.
Superior Sealing Performance: Engineered with high-grade sealing materials and precision manufacturing techniques, the valve achieves exceptional sealing integrity when closed, enhancing reliability and minimizing leakage risks.
Durable Construction: Constructed from corrosion-resistant materials and featuring specially treated internal components, the valve offers outstanding durability and longevity even in challenging operating environments.
User-Friendly Design: Designed for ease of operation and maintenance, the valve's intuitive design promotes operational efficiency and enhances safety protocols during installation and regular service intervals.
Versatile Applications: Suitable for a wide range of industries including water treatment, chemical processing, oil and gas, and various fluid handling applications, the valve adapts seamlessly to diverse operational requirements, ensuring reliable performance under varying conditions.
FAQ
Q: What sets the Screw Down Check Globe Valve apart for industrial applications?
A: The valve features a robust check mechanism ensuring unidirectional fluid flow, crucial for preventing backflow and minimizing pressure loss in industrial fluid control systems.
Q: How does the valve ensure longevity in harsh environments?
A: Constructed from corrosion-resistant materials with specially treated internal components, it excels in durability, making it ideal for demanding industrial conditions.
Q: Can the Screw Down Check Globe Valve handle extreme temperatures?
A: Yes, it operates effectively across a broad temperature range from -29°C to +425°C, depending on material specifications.
Q: Which industries benefit most from this valve?
A: Versatile and adaptable, it serves industries such as water treatment, chemical processing, oil and gas, and diverse fluid handling systems requiring reliable performance and efficient sealing.
