90 Reducing Elbow
The main function of these fittings is to connect pipes or to change the direction of fluid flow.
Description
The 90 Reducing Elbow is a versatile plumbing fitting designed for easy installation and seamless connections in piping systems. Crafted from durable malleable iron, this elbow ensures superior strength and longevity. Its precision-engineered 90° angle and reducing sizes allow smooth transitions between pipes of different diameters, enabling efficient fluid flow while reducing potential leaks. Ideal for various applications, this elbow offers reliability and adaptability in diverse plumbing setups.
Technical Parameters
1.Drawing
2.DIMENSIONS(mm)
| Size | A | B | Unit Weight | Packing | ||
| Black | Galv. | Carton | ||||
| BSPT | DN | mm | mm | g | g | Pcs/ctn |
| 1/2"×3/8" | 15x10 | 25 | 25 | 74.48 | 76 | 270 |
| 3/4"×1/2" | 20x15 | 29 | 30 | 122.5 | 125 | 270 |
| 1"×3/8" | 25x10 | 29 | 31 | 143.08 | 146 | 160 |
| 1"×1/2" | 25x15 | 31 | 33 | 161.7 | 165 | 160 |
| 1"×3/4" | 25x20 | 34 | 35 | 184.24 | 188 | 160 |
| 1-1/4"×1/2" | 32x10 | 31 | 36 | 213.64 | 218 | 100 |
| 1-1/4"×1/2" | 32x15 | 34 | 37 | 227.36 | 232 | 100 |
| 1-1/4"×3/4" | 32x20 | 36 | 40 | 252.84 | 258 | 100 |
| 1-1/4"×1" | 32x25 | 40 | 41 | 285.18 | 291 | 90 |
| 1-1/2"×1/2" | 40x15 | 35 | 41 | 266.56 | 272 | 90 |
| 1-1/2"×3/4 | 40x20 | 37 | 43 | 302.82 | 309 | 90 |
| 1-1/2"×1" | 40x25 | 41 | 45 | 342.02 | 349 | 70 |
| 1-1/2"×1-1/4" | 40x32 | 45 | 47 | 400.82 | 409 | 56 |
| 2"×1/2" | 50x15 | 37 | 47 | 398.86 | 407 | 68 |
| 2"×3/4" | 50x20 | 40 | 49 | 423.36 | 432 | 52 |
| 2"×1" | 50x25 | 43 | 51 | 476.28 | 486 | 50 |
| 2"×1-1/4" | 50x32 | 47 | 53 | 552.72 | 564 | 40 |
| 2"×1-1/2" | 50x40 | 51 | 54 | 588 | 600 | 30 |
| 2-1/2"×1/2" | 65x15 | 40.5 | 56 | 579.18 | 591 | 46 |
| 2-1/2"×3/4" | 65x20 | 43.5 | 57 | 613.48 | 626 | 40 |
| 2-1/2"×1" | 65x25 | 47.5 | 59 | 686 | 700 | 34 |
| 2-1/2"×1-1/4" | 65x32 | 51.5 | 61 | 732.06 | 747 | 30 |
| 2-1/2"×1-1/2" | 65x40 | 54.5 | 61 | 772.24 | 788 | 26 |
| 2-1/2"×2" | 65x50 | 59.5 | 64 | 904.54 | 923 | 24 |
| 3"×1/2" | 80x15 | 42.5 | 64 | 735.98 | 751 | 36 |
| 3"×3/4" | 80x20 | 45.5 | 65 | 770.28 | 786 | 30 |
| 3"×1" | 80x25 | 49.5 | 67 | 830.06 | 847 | 20 |
| 3 "×1-1/4" | 80x32 | 54.5 | 69 | 931.98 | 951 | 20 |
| 3 X 1-1/2" | 80x40 | 57.5 | 71 | 952.56 | 972 | 20 |
| 3"×2" | 80x50 | 61.5 | 71 | 1166.2 | 1190 | 12 |
| 3"×2-1/2" | 80x65 | 71.5 | 74 | 1319.08 | 1346 | 12 |
| 4"×1/2" | 100x15 | 49.5 | 78 | 1311.24 | 1338 | 14 |
| 4"×3/4" | 100x20 | 53.5 | 79 | 1326.92 | 1354 | 14 |
| 4"×1" | 100x25 | 56.5 | 82 | 1405.32 | 1434 | 14 |
| 4"×1-1/4" | 100x32 | 60.5 | 85 | 1550.36 | 1582 | 14 |
| 4"×1-1/2" | 100x40 | 62.5 | 85 | 1621.9 | 1655 | 10 |
| 4"×2" | 100x50 | 68.5 | 86 | 1711.08 | 1746 | 10 |
| 4"×2-1/2" | 100x65 | 77.5 | 89 | 1957.06 | 1997 | 8 |
| 4"×3" | 100x80 | 82.5 | 90 | 2164.82 | 2209 | 8 |
Product advantage
Durable Construction: Made from high-quality malleable iron, ensuring long-lasting durability and resistance to corrosion, making it suitable for various environments.
Precision Engineering: Engineered with precision for a perfect 90° angle and reducing sizes, facilitating seamless transitions between different pipe diameters, ensuring optimal flow efficiency.
Versatile Applications: Suited for a wide range of applications, from residential plumbing to industrial settings, providing adaptability and reliability across diverse piping systems.
Ease of Installation: Designed for easy installation,90 Reducing Elbow allow for swift and hassle-free integration into existing or new piping configurations.
Leak-Resistant Design: Constructed to minimize potential leaks, ensuring a tight and secure connection between pipes of varying sizes, promoting system integrity and efficiency.
FAQ
Q: What is malleable iron, and why is it used for these elbows?
A: Malleable iron is a type of cast iron that's been treated to become more ductile and durable. It's used for these elbows due to its strength, resistance to fracture, and suitability for shaping into precise fittings.
Q: Can these elbows be used for both gas and water systems?
A: Yes, these elbows are versatile and suitable for use in both gas and water systems, providing reliable connections in various applications.
Q: Are 90 Reducing Elbows compatible with different pipe materials?
A: Generally, these elbows are designed to be compatible with various pipe materials such as steel, iron, brass, or copper, offering flexibility in usage.
Q: What's the maximum pressure these elbows can withstand?
A: The pressure rating typically depends on the specific size and design. Always check the product specifications for the exact pressure ratings as they may vary based on dimensions and intended use.
Q: Do these elbows require special tools for installation?
A:No specialized tools are usually required for installation. However, ensuring a proper fit and tight seal may involve basic plumbing tools such as wrenches or pipe tape for secure connections. Always follow manufacturer guidelines for installation procedures.
