Split Flange Fitting
Versatile Compatibility: Compatible with diverse pipe materials for flexibility.
Description
A Split Flange Fitting is a versatile and efficient component used in piping systems for connecting and disconnecting pipes or tubes. Its design consists of two symmetrical halves that can be easily assembled around the pipe, forming a secure and leak-proof connection when tightened. This split design eliminates the need to disassemble the entire piping system for maintenance or repairs, making it a time-saving and cost-effective solution. Split flanges are commonly employed in a variety of industries, including plumbing, HVAC, and industrial applications, providing a reliable and convenient method for joining or separating pipes with minimal downtime.
Technical Parameters
1.Drawing
2.Dimension(mm)
| Nominal Size |
Pipe O.D | Working Pressure | Dimensions | Bolt/Nut Size | |||
| mm/in | mm/in | PSI/Mpa | A(mm/in) | B(mm/in) | D(mm/in) | φ (mm/in) | No.-Size(mm) |
| 65 | 76.1 | 225PSI 1.6MPa |
230 | 18.5 | 145 | 185 | 4-φ18 |
| 2 | 2.996 | 9.06 | 0.73 | 5.71 | 7.28 | ||
| 80 | 88.9 | 254 | 18.5 | 160 | 200 | 8-φ18 | |
| 3 | 3.500 | 10.00 | 0.73 | 6.30 | 7.87 | ||
| 100 | 114.3 | 272 | 18.5 | 180 | 220 | 8-φ18 | |
| 4 | 4.500 | 10.71 | 0.73 | 7.09 | 8.66 | ||
| 125 | 139.7 | 305 | 21.5 | 210 | 250 | 8-φ18 | |
| 5 | 5.500 | 12.01 | 0.85 | 8.27 | 9.84 | ||
| 150 | 165.1 | 340 | 21.5 | 240 | 285 | 8-φ22 | |
| 56 | 6.500 | 13.39 | 0.85 | 9.45 | 11.22 | ||
| 200 | 219.1 | 400 | 24.5 | 295 | 340 | 12-φ22 | |
| 8 | 8.626 | 0.96 | 11.61 | 13.39 | 13.39 | ||
Product advantage
Efficient Maintenance: Split Flange Fitting facilitate quick and easy maintenance of piping systems. Their design allows for rapid disassembly and reassembly, minimizing downtime during repairs or component replacement.
Cost-Effective Solution: The split flange design eliminates the need to dismantle the entire piping structure for maintenance, reducing labor costs and saving valuable time. This makes split flanges a cost-effective choice for industries seeking efficient solutions.
Versatile Application: Split Flange Fitting find widespread use in various industries, such as plumbing, HVAC, and industrial settings. Their adaptability makes them suitable for connecting or disconnecting pipes in diverse environments and applications.
Leak-Proof Performance: When properly installed and tightened, split flanges provide a secure and leak-proof connection. This reliability ensures the integrity of the piping system, preventing costly leaks and potential damage to equipment.
Time-Saving Installation: The straightforward assembly process of split flanges streamlines installation, saving time and effort for engineers and technicians. This advantage is particularly valuable in projects where efficiency and speed are crucial factors.
FAQ
Q: How do split flanges differ from traditional flanges?
A: Split flanges have a unique design, featuring two halves that can be assembled around a pipe without requiring complete system disassembly. This sets them apart from traditional flanges, offering a more convenient solution for maintenance and repairs.
Q: What types of piping systems are compatible with split flanges?
A: Split Flange Fitting are versatile and can be used in various applications, including plumbing, HVAC, and industrial settings. They are compatible with a wide range of pipes and tubing materials, making them suitable for diverse piping systems.
Q: Are split flanges suitable for high-pressure environments?
A: Yes, split flanges are designed to provide a secure and leak-proof connection, making them suitable for use in high-pressure environments. However, it is essential to ensure proper installation and tightening to maintain their integrity under elevated pressure conditions.
Q: Can it be reused after disassembly?
A: In many cases, split flanges can be reused after disassembly. However, it is crucial to inspect the components for any signs of wear, damage, or deformation before reusing them. Proper maintenance and care during disassembly and reassembly contribute to their longevity.
Q: Do these flanges require special tools for installation?
A: While split flanges generally do not require specialized tools for installation, it is recommended to use appropriate wrenches or tools to ensure proper tightening. Following the manufacturer's guidelines and using the correct tools will help achieve a secure and reliable connection.
